CHINA STAR-B SERIES CHAIN FEEDING PRINTING SLOTTING MACHINE(STANDARD CONFIGURATION)

Function and Characteristics:

Feeding department: It adopt the combination chain-paper feeding style, ensure paper feeding steady, reduce the rate of spoiled productsPrinting department:

◎Adopt computer-digit phase controller, input the digit adjustment phase directly, adjust quickly and precisely.

◎Auto rise the ink plate ,the inker turning to prevent ink dried

◎Adopt electrically separation,pneumatic locking and pneumatic brake.

◎Ink supply by pneumatic diaphragm pump.

◎Main transmission gear made by 45# steel , it adopting helical gear driving and processed by high frequency quenching. Auto sprinkle lubricating system, ensure the machine

precise and use life.Die-cutting and slotting department:

◎Down knives cushion adopt import rubber cushion., down axle can be lift-lower by pneumatic, not spoil the rubber cushion when axle no-load running and adjusting phase.

◎Down axle can auto movement transversely, rotary die-cutter auto change position, ensure cut mark never reiteration. the rubber cushion use life has greatly enhanced.

◎Up knives adopt import euro rule , it installed on the mould very conveniently,increase the rubber cushion use life ,suggestion the customer use it.

◎Adopt posttensioning out the paper , easy dispose of paper trimmings.

◎Electric phase adjusting convenient and quick, Graduated plate show.

◎Main gear of transmission part thickness is 50mm, it use 45# steel , adopting helical gear driving and processed by high frequency quenching. Auto sprinkle lubricating

system, ensure the machine precise and use life

◎All pressure adjustment by turbine box.

◎All machine control on worker side ,save adjust time.
